LG LG-E960 - Page 305

12. EXPLODED VIEW & REPLACEMENT PART LIST
- 305 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
L1213
L1217
L1232
L1233
Inductor
Multilayer,Chip
EAP62227801
LG HK 0603 12NJ-T 12NH 5% - 190mA - -
0.68OHM 2.7GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6 R11011 Resistor,Chip ERHY0009311
MCR006YZPF51R0 51OHM 1% 1/20W 0603 R/TP
- ROHM.
6
C21005
C21006
Capacitor
Ceramic,Chip
ECCH0009504
MCH032A180JK 18pF 5% 25V NP0 -55TO+125C
0603 R/TP - ROHM.
6 D7002 Diode,TVS EAH61872501
PESD5V0S1UA 5V 6.2V min. 9.8V 47A 360mW
SOD323 R/TP 2P 1 NXP Semiconductors
6 R6007 Resistor,Chip ERHY0000254
MCR01MZP5J472 4.7KOHM 5% 1/16W 1005 R/TP
- ROHM.
6
R21007
R21008
Resistor,Chip EBC61997301
MCR004YZPF4701 4.7KOHM 1% 1/32W 0402
R/TP - ROHM CO.,LTD.
6
R1101
R21018
R7013
Resistor,Chip ERHY0009303
MCR006YZPF1002 10KOHM 1% 1/20W 0603 R/TP
- ROHM.
6 CN10001 Connector,BtoB ENBY0040301
GB042-34S-H10-E3000 34P 0.4MM STRAIGHT
SOCKET SMD R/TP 1M - LS Mtron Ltd.
6 L11045
Inductor
Multilayer,Chip
EAP62227601
LG HK 0603 6N8J-T 6.8NH 5% - 250mA - -
0.39OHM 3.9GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6
C6011
C6012
C6013
Capacitor
Ceramic,Chip
ECCH0007901
CE AMK107 BJ106MA-T 10uF 20% 4V X5R -
55TO+85C 1608 R/TP 0.8+/- 0.1 - TAIYO YUDEN
CO.,LTD
6 U11007
IC,DC,DC
Converter
EAN62067401
LM3242TMX NOPB 2.7 to 5.5V adj 0W CSP R/TP
9P - NATIONAL SEMICONDUCTOR ASIA
PACIFIC PTE. LTD.
6 L1214
Inductor
Multilayer,Chip
EAP61987001
HK0603 18NH-T 18NH 3% - 140mA - - 1.05OHM
2.3GHZ 21 SHIELD 0 0.6X0.3X0.3MM R/TP TAIYO
YUDEN CO.,LTD
