12. EXPLODED VIEW & REPLACEMENT PART LIST
- 306 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C15025
C15026
C15027
C15028
C15029
C23013
C6018
C7021
C7022
C9038
Capacitor
Ceramic,Chip
EAE62502901
CL05A106MP5NUNC 10uF 20% 10V X5R -
55TO+85C 1005 R/TP 0.55T max. SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 R7011 Resistor,Chip ERHY0035601
PMR10EZPFU10L0 0.01OHM 1% 1/2W 2012 R/TP
- ROHM.
6
FL6002
FL6003
FL6004
FL6006
Filter,EMI/Power EAM62530001
ACFE2B4G101E COMMON MODE NOISE FILTER
- 1.2pF 0H SMD R/TP 4ch-CMEF AMOTECH CO.,
LTD.
6 C8004
Capacitor
Ceramic,Chip
ECCH0000147
MCH155CN222KK 2.2nF 10% 50V X7R -
55TO+125C 1005 R/TP - ROHM.
6 R6023 Resistor,Chip EBC62337901
RK73H1FTQTBL1003F 100KOHM 1% 1/32W 0402
R/TP 0402 100000 ohm 1% KOA CORPORATION.
6
L11000
L11009
Inductor
Multilayer,Chip
EAP62227001
LG HK 0603 1N2S-T 1.2NH 0.3NH - 450mA - -
0.12OHM 10GHZ 4 SHIELD - 0.6X0.3X0.3MM R/TP
TAIYO YUDEN CO.,LTD
6
R200
R201
R202
Resistor,Chip ERHY0009501
MCR006YZPJ000 0OHM 5% 1/20W 0603 R/TP -
ROHM.
6 U12001
IC,RF
Transceiver,4G
EAN62336401
WTR1605L EDGE/CDMA/UMTS/HSPA+/LTE with
MSM8960 CSP R/TP 142P QUALCOMM
INCORPORATED.
6 R7005 Resistor,Chip EBC62259801
RC0402FR-07105KL 105KOHM 1% 1/16W 1005
R/TP 0.37T max. (mm) YAGEO CORPORATION
6
ZD6003
ZD6005
Diode,TVS EAH61533301
RCLAMP0521PA.TCT 5V 6V min. / 9.3V typ. / 11V
max. 15V 4A - SLP1006P2 R/TP 2P 1 SEMTECH
INTERNATIONAL AG
6 U8003
IC,Acceleration
Sensor
EAN62239601
BMP180 Pressure Sensor 3.6X3.8X9.3 LGA R/TP
7P Pressure Sensor BOSCH SENSORTEC GMBH
6 L11066
Inductor
Multilayer,Chip
ELCH0003847
LQG15HS1N8S02D 1.8NH 0.3NH - 300mA 0.1OHM
6GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
MURATA MANUFACTURING CO.,LTD.
