12. EXPLODED VIEW & REPLACEMENT PART LIST
- 307 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 R10002 Resistor,Chip ERHY0009527
MCR006YZPJ473 47KOHM 5% 1/20W 0603 R/TP -
ROHM.
6 R1200 Resistor,Chip ERHZ0000310
MCR01MZP5F6800 680OHM 1% 1/16W 1005 R/TP
- ROHM.
6
C11004
C11006
Capacitor
Ceramic,Chip
ECCH0009520
MCH032A150JK 15pF 5% 25V X7R -55TO+125C
0603 R/TP - ROHM.
6 C1200
Capacitor
Ceramic,Chip
ECCH0009502
GRM0335C1E1R5CD01D+A02 1.5pF 0.25PF 25V
NP0 -55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 R7024 Resistor,Chip ERHY0009307
MCR006YZPF4703 470KOHM 1% 1/20W 0603
R/TP - ROHM.
6
R10005
R10006
R10007
Resistor,Chip ERHY0024601
RC0603J151CS 150OHM 5% 1/20W 0603 R/TP -
SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 C9035
Capacitor
Ceramic,Chip
ECZH0025920
GRM033R71C102K 1nF 10% 16V X7R -
55TO+125C 0603 R/TP - - MURATA
MANUFACTURING CO.,LTD.
6
C1204
L1215
L1271
Inductor
Multilayer,Chip
EAP61866601
LG HK0603 R10J-T 100NH 5% - 60mA - - 3.74OHM
900MHZ 4 SHIELD 0 0.6X0.3X0.3MM R/TP TAIYO
YUDEN CO.,LTD
6
R9001
R9002
R9010
Resistor,Chip ERHY0009526
MCR006YZPJ472 4.7KOHM 5% 1/20W 0603 R/TP
- ROHM.
6 FL1207 Filter,Saw SFSY0034902
B9470 1960
MHz,1.4*1.1*0.45,SMD,1930M~1990M,IL
4.0,5pin,U-B,50-100,BAND II
DIVERSITY,1960MHz,1.4*1.1*0.45,SMD,R/TP
EPCOS PTE LTD.
6
C11097
C23003
C23004
C23007
C24001
C24002
C24008
C24009
Capacitor
TA,Conformal
EAE62748301
F981A226MMALZT 22uF 20% 10V 11UA -
55TO+125C 8OHM 1.6X0.85X0.8MM NONE SMD
R/TP 0.9T max. NICHICON CORPORATION
6 CN7001
Connector,Terminal
Block
EAG63110101
WB22457-1404-7F 4P 2.00MM STRAIGHT SMD
R/TP Invaded Battery connector FOXCONN
6
C7016
C7017
Capacitor
Ceramic,Chip
ECCH0009514
MCH032A(AN)100DK 10pF 0.5PF 25V X7R -
55TO+125C 0603 R/TP - ROHM.
