12. EXPLODED VIEW & REPLACEMENT PART LIST
- 308 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 CN6001 Connector,BtoB ENBY0034201
GB042-24S-H10-E3000 24P 0.40MM STRAIGHT
SOCKET SMD R/TP 1M - LS Mtron Ltd.
6 L1234
Inductor
Multilayer,Chip
EAP62108401
LQP03TG12NJ02D 12NH 5% - 180mA - - 1.78OHM
3.7GHZ 11 SHIELD - 0.6X0.3X0.3MM R/TP
MURATA MANUFACTURING CO.,LTD.
6 L11041
Inductor
Multilayer,Chip
EAP62227301
LG HK 0603 2N2S-T 2.2NH 0.3NH - 360mA - -
0.19OHM 8.8GHZ 4 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6
ZD6014
ZD6015
Diode,TVS EDTY0010501
RCLAMP1521P.TCT 15V 16.7 28V 4A 0W
SLP1006P2 R/TP 2P 1 SEMTECH
CORPORATION
6 R11010 Resistor,Chip ERHY0042406
RC0201JR-0751KL 51KOHM 5% 1/20W 0603 R/TP
- YAGEO CORPORATION
6 FL1202 Filter,Saw SFSY0028201
SAFEB2G14FB0F00 - - - - 2P MURATA
MANUFACTURING CO.,LTD.
6 R1107 Resistor,Chip ERHZ0000235
MCR01MZP5F2000 200OHM 1% 1/16W 1005 R/TP
- ROHM.
6 U7002 IC,Load Switch EAN62403501
FPF1039BUCX 1.2 to 5.5V 4.4SEC 32SEC 1.2W
CSP R/TP 6P Load Switch FAIRCHILD
SEMICONDUCTOR
6
C5021
C5022
Capacitor
Ceramic,Chip
EAE62422701
CL02C330JO2ANNC 33pF 5% 16V C0G -
55TO+125C 0402 R/TP 0.22T max. SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
C11018
C11020
C1209
Inductor
Multilayer,Chip
EAP62225901
LQP03TG1N0C02D 1NH 0.2NH - 600mA - -
0.15OHM 6GHZ 12 SHIELD - 0.6X0.3X0.3MM R/TP
MURATA MANUFACTURING CO.,LTD.
6
C13004
C9034
Capacitor
Ceramic,Chip
ECCH0009106
C0603X7R1C103KT 10nF 10% 10V X7R -
55TO+125C 0603 R/TP - TDK CORPORATION
6 C9005
Capacitor
Ceramic,Chip
EAE62522101
CL10A226MP8NUNE 22uF 20% 10V X5R -
55TO+85C 1608 R/TP 1.05T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
C15010
C15012
C15013
C15014
C23027
C23029
C23030
C23033
Capacitor
Ceramic,Chip
ECCH0017501
CL10A226MQ8NRNE 22uF 20% 6.3V X5R -
55TO+85C 1608 R/TP 0.8MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
