12. EXPLODED VIEW & REPLACEMENT PART LIST
- 309 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C23014
C6001
Capacitor
Ceramic,Chip
ECCH0007803
CL10A106MP8NNNC 10uF 20% 10V X5R -
55TO+85C 1608 R/TP 0.8MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
L11061
L11069
Capacitor
Ceramic,Chip
ECCH0009208
GRM0335C1ER50C 0.5pF 0.25PF 25V X7R -
55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 C11091
Capacitor
Ceramic,Chip
ECCH0009228
GRM033R61A472K 4700pF 10% 10V X5R -
55TO+85C 0603 R/TP - - MURATA
MANUFACTURING CO.,LTD.
6 SW11000 Connector,RF ENWY0005501
20279-001E-01 NONE STRAIGHT SOCKET SMD
R/TP AU 50OHM 400mDB I-PEX CO., LTD
6 U6002
IC,DC,DC
Converter
EAN62416701
DW8752B 2.9 ~ 4.5V +5.5V , -5.4V (70mA) 0W
UDFN R/TP 12P - DONGWOON ANATECH
CO.,LTD.
6 C9029
Capacitor
Ceramic,Chip
EAE62944801
GRM155R60J334K 330nF -10TO+10% 6.3V X5R -
55TO+85C 1005 R/TP 0.5T L:1.0+-0.05 W:0.5+-
0.05 T:0.5+-0.05 MURATA MANUFACTURING
CO.,LTD.
6 C6019
Capacitor
Ceramic,Chip
EAE62505701
CL10A105KB8NNNC 1uF 10% 50V X5R -
55TO+85C 1608 R/TP 0.9T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 R1114 Resistor,Chip EBC62236701
RC0402FR-074K75L 4.75KOHM 1% 1/16W 1005
R/TP 0.4T max. YAGEO CORPORATION
6 FL1206 Filter,Saw SFSY0040602
B9461 942.5MHz 1.4*1.1*0.45 SMD R/TP 5P
EPCOS PTE LTD.
6 L11062
Inductor,Wire
Wound,Chip
ELCP0014001
CIG21LR47MNE 470NH 20% - 1.3A 1.4 1.3
0.08OHM - - SHIELD 2X1.25X1MM NONE R/TP
SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 R23002 Resistor,Chip ERHZ0000701
MCR03EZP5J000 0OHM 5% 1/10W 1608 R/TP -
ROHM.
6 L1200
Inductor
Multilayer,Chip
EAP61866301
LG HK0603 5N1S-T 5.1NH 0.3NH - 270mA - -
0.33OHM 5GHZ 5 SHIELD 0 0.6X0.3X0.3MM R/TP
TAIYO YUDEN CO.,LTD
6
R15007
R23018
Resistor,Chip ERHZ0000204
MCR01MZP5F1003 100KOHM 1% 1/16W 1005
R/TP - ROHM.
6
Q13001
Q21001
FET EBK61952101
KTJ6131V P-CHANNEL MOSFET -30V +-20 -0.05A
40OHM 100mW VSM R/TP 3P KEC
CORPORAITION
