12. EXPLODED VIEW & REPLACEMENT PART LIST
- 311 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 U8001 IC,Motor Driver EUSY0200803
SM100 MLF ,8 ,R/TP ,Haptic Driver IC,2X2 ,;
,IC,Motor Driver SYNCOAM CO.,LTD.
6 R5007 Resistor,Chip ERHY0009586
MCR006YZPF2201 2.2KOHM 1% 1/20W 0603
R/TP - ROHM.
6 ZD6001 Diode,TVS EDTY0009101
ESD9X5.0ST5G 5V 6.2 12.3V 8.7A 107W SOD528
R/TP 2P 1 ON SEMICONDUCTOR
6 R23003 Resistor,Chip EBC61996201
MCR004YZPF1003 100KOHM 1% 1/32W 0402
R/TP - ROHM CO.,LTD.
6 FL10001 Filter,LCR EAM62451101
ICMEF112P350MFR COMMON MODE NOISE
FILTER 0HZ 0F 0H SMD R/TP Common mode
Impedance at 100MHz : 35ohm+-30%, DC
Resistance Max :3.0ohm INNOCHIPS
TECHNOLOGY
6 CN21001 Connector,BtoB ENBY0053701
14-5804-030-000-829+
30,mm,STRAIGHT,0.40MM,MALE, KYOCERA
ELCO KOREA SALES CO.,LTD.
6 R6017 Resistor,Chip EBC61976601
MCR004YZPF2702 27KOHM 1% 1/32W 0402 R/TP
- ROHM CO.,LTD.
6 L11071
Inductor
Multilayer,Chip
ELCH0004710
1005GC2T15NJLF 15NH 5% - 250mA 0.53OHM
2GHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
PILKOR ELECTRONICS LTD.
6 U6001
IC,DC,DC
Converter
EAN61850201
LM3559TLX 2.5 to 5.5V adj 0W MICRO SMD R/TP
16P - NATIONAL SEMICONDUCTOR ASIA
PACIFIC PTE. LTD.
6 R6025 Resistor,Chip ERHZ0000350
MCR01MZP5F6203 620KOHM 1% 1/16W 1005
R/TP - ROHM Semiconductor KOREA
CORPORATION
6 U7003 IC,Reset EUSY0429601
FT8010UMX UMLP ,10 ,R/TP ,Reset IC (Timer) ,;
,IC,Voltage Detector FAIRCHILD
SEMICONDUCTOR HONG KONG LTD.
6 PT11000 Thermistor,NTC SETY0007001
NCP15WD683J03RC 68KOHM 5% 0V 0A 4.15KK
SMD P/TP 1005size MURATA MANUFACTURING
CO.,LTD.
6 FL1201 Filter,Saw SFSY0030005
SAFEA881MFR0F00 881.5MHz 1.4*1.1*0.5 SMD
R/TP 5P MURATA MANUFACTURING CO.,LTD.
6 R7006 Resistor,Chip ERHZ0000224
MCR01MZP5F1602 16KOHM 1% 1/16W 1005
R/TP - ROHM.
