12. EXPLODED VIEW & REPLACEMENT PART LIST
- 312 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 C1114
Capacitor
Ceramic,Chip
ECZH0001215
C1005X5R1A105KT000F 1uF 10% 10V X5R -
55TO+85C 1005 R/TP - TDK KOREA
COOPERATION
6 U10001 IC,Comparator EUSY0250501
NCS2200SQ2T2G NCS2200SQ2T2G,SC70,5
PIN,R/TP,Comparator,pin compatible to
EUSY0077701 - - SC70 R/TP 5P - ON
SEMICONDUCTOR
6 U8005
IC,Geomagnetic
Sensor
EAN62333101
AK8963C 3 Axis Geomagnetic Sensor 1.6X1.6X0.5t
CSP R/TP 14P - ASAHI KASEI CORPORATION
6 C5027
Capacitor
Ceramic,Chip
ECCH0007805
CL05A106MQ5NUNC 10uF 20% 6.3V X5R -
55TO+85C 1005 R/TP 0.5+-0.05 SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 ZD7004 Diode,TVS EDTY0012102
PESD5V0V1BL 5V 5.8V min. 12.5V 4.8A 45W
SOD-882 R/TP 2P 1 STC CORP.
6 U6005
IC,LDO Voltage
Regulator
EUSY0367001
RP101K332D RP101K332D
RP101K332D,DFN1612-4B ,4 ,R/TP ,300mA 3.3V
LDO RICOH COMPANY, LTD. RICOH COMPANY,
LTD.
6 CN6003 Connector,BtoB ENBY0040701
GB042-30S-H10-E3000 30P 0.4MM STRAIGHT
FEMALE SMD R/TP 1M - LS Mtron Ltd.
6 C11106
Inductor
Multilayer,Chip
ELCH0003832
LQG15HS2N2S02D 2.2NH 0.3NH - 300mA - -
0.12OHM 6GHZ 8 SHIELD NONE 1.0X0.5X0.5MM
R/TP MURATA MANUFACTURING CO.,LTD.
5 SAD010000 Software,Mobile SAD33554101 Base V09i - WORLD WIDE QCT -
4 EBR071500
PCB Assembly
Main,Insert
EBR76285101 LGE960.AUSGBK 1.2 Main
5 EBP00 Camera Module EBP61602001
C1FA-Y411A C1FA-Y411A 1.3M Sony 1/7.8",
5x5x3.0t, HD, MIPI, FPCB 3.5mm 75deg LG
INNOTEK CO., LTD
33
5 RAA050100 Resin,PC BRAH0001301 UF2040 or 3075BHF . . NONE
5 EBP01 Camera Module EBP61602102
C8AA-Y412D C8AA-Y412D 8M AF(VCM),
Sony(1/4") BSI, 8.5x8.5x4.75t, MIPI, FPCB, 90
degree LG INNOTEK CO., LTD
34
2 EAD010000 Cable,Assembly EAD62330101
IFS0003D USB USB 1.2M 5 BLACK. UL N
INTERFACESAMIL CO.,LTD
