LG LHD427 User Manual

Appendix38
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption
Refer to main label.
Networked standby 0.5 W (If all network ports are activated.)
Dimensions (W x H x D) Approx. 360 mm x 58 mm x 293 mm without foot
Net Weight (Approx.) Approx. 2.3 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply 5 V
0
500 mA
Inputs/ Outputs
VIDEO OUT 1.0 V (p-p), 75
Ω
, sync negative, RCA jack x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) x 1
ANALOG AUDIO IN 2.0 Vrms (1KHz, 0dB), 600
Ω
RCA Jack (L,R) X 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1
Amplier
Stereo mode 42 W + 42 W (3
Ω
at 1kHz)
Surround mode
Front 42 W + 42 W (3
Ω
at 1kHz)
Center 42 W (3
Ω
at 1 kHz)
Surround 42 W + 42 W (3
Ω
at 1kHz)
Subwoofer 120 W (4
Ω
at 60 Hz)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz

LG LHD427 Specifications

General

Brand	LG
Model	LHD427
Category	Home Theater System
Language	English
