LG LHD627 - Product Technical Specifications

Appendix42
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D) Approx. 360 x 58 x 298.5 mm without foot
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Bus Power Supply 5 V
0
500 mA
Inputs/ Outputs
VIDEO OUT 1.0 V (p-p), 75
Ω
, sync negative, RCA jack x 1
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) x 1
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600
Ω
, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1
Amplier
Stereo mode 167 W RMS + 167 W RMS (3
Ω
at 1kHz)
Surround mode
Front 167 W RMS + 167 W RMS (3
Ω
at 1 kHz)
Center 167 W RMS (3
Ω
at 1 kHz)
Surround 167 W RMS + 167 W RMS (3
Ω
at 1 kHz)
Subwoofer 167 W RMS (3
Ω
at 60 Hz)
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
