Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T ·······················Starts / Pauses playback.
I ·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
SPEAKERS ··················· Connect to speakers.
ANTENNA FM ·········· Connect to radio antenna.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
HDMI OUT TO TV··················· Connect to TV.
OPTICAL IN ·············· Connect to digital device.
Speaker Connection2Speaker Assembling1
Speaker design and connection method may
be different according to models.
,
Front
(Right)
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left)
Surround
(Right)
Small
screw
Small
screw
Big
screw
(Sold separately)
