MAINTENANCE
OVEN LIGHT REPLACEMENT
1. Unplug the oven or turn off power at the main
power supply and wear gloves.
2.
Remove the vent cover mounting screws.
(2 outside screws)
3. Tip the cover forward, then lift out to remove.
4.
Remove the cover screw,pull the cover
forward and then lift up the bulb holder.
5. Replace the bulb with a 30 watt appliance bulb.
6.
Replace the bulb holder and screw.
7. Slide the top of the vent cover into place. Push
the bottom until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply.
COOKTOP/NIGHT LIGHT
REPLACEMENT
3. Replace the bulb with a 30 watt appliance bulb.
4. Replace the bulb cover and mounting screws.
5. Turn the power back on at the main power supply.
2. Remove the bulb cover mounting screws.
1. Unplug the oven or turn off power at the
main power supply.
7.
Slide the bottom of the vent cover into place. Push
the top until it snaps into place. Replace the
mounting screws. Turn the power back on at the
main power supply and set the clock.
6. Slide a new charcoal filter into place and close the
door. The filter should rest at the angle shown.
4. Open the door.
5.
Remove the old filter.
- 27 -

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG LMV1831SW and is the answer not in the manual?

LG LMV1831SW Specifications

General IconGeneral
Styleover-the-range
Colorwhite, smooth white
Total Capacity1.8 cubic feet
Sensor Cookingyes
Child Lockyes
Timeryes
Microwave Power1000 watts
Voltage120 volts
Current15 amperes
Weight and Dimensions IconWeight and Dimensions
Depth15.37 inches
Height16.43 inches
Width29.93 inches
Net Weight48.5 pounds
