- 18 -
Remove the screws on both the left and
right rails.
Grasp the drawer on each side and pull it up
to separate it from the rails.
With both hands, hold each rail and push it in
to allow both rails to slide in simultaneously.
With both hands, pull out each rail
simultaneously until both rails are fully
extended.
Grasp the drawer on each side and hook
the door supports
1
into the rail tabs
2
located on both sides.
Lower the door into final position and
Reconnect the wire harness to the
connection at the end of the right rail.
tighten the screws located on both sides.
