16 INSTALLATION
2 Grasp the drawer on each side and hook the
drawer supports into the rail tabs located on
both sides.
• Do not hold the handle when removing or
replacing the drawer. The handle may come off,
causing personal injury.
3 Lower the door into its final position and
insert the screws in the rails on both sides.
4 Insert the Durabase basket in the rail
assembly.
5 Insert the drawer into the frame, and push
the drawer back until it clicks into place.
Replace the ice bin in the drawer.
Assembling the Refrigerator Door
1 Make sure that the hinge pin sleeve is
inserted in the bottom of the door. Lower the
door onto the middle hinge pin.
2 Align the door with the cabinet.
3 Fit the hinge a over the hinge lever latch b
and slot it into place. Rotate the lever
c
counterclockwise to secure the hinge.
4 Replace the hinge cover d. Insert and tighten
the cover screws
e.
