This LG Service Manual, “30” Freestanding Self-Cleaning Electric Range,” provides the technician with information on the operation
and service of the Freestanding Self-Cleaning Electric Range. It is to be used as a training Service Manual. For specific information
on the model being serviced, refer to the “Owner’s Manual” or “Tech Sheet” provided with the electric range.
SAFETY PRECAUTIONS
• Repairs of the appliance should be carried out by a licensed technician only. Incorrect repairs may result in dangerous situations. If
you need repairs, contact an LG Service Center or your dealer.
• If the power cord is defective, it must be replaced by a qualified service agent with a UL listed range cord.
• Electrical leads and cables should not be allowed to touch the oven.
• Rating plate is located on the left side of warming drawer.
• The power supply of the appliance should be turned off when it is being repaired.
LG Electronics assumes no responsibility for any repairs made on our products by anyone other than Authorized Service Technicians.
FORWARD
• DISCONNECT power supply cord from the outlet before servicing.
• Replace all panels and parts before operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal injury, death or electrical shock.
• DO NOT Touch when the oven operates.
- The interior parts will be very hot.
WARNING

LG LRE3193BD Specifications

General

Clock type	Electronic
Control type	Touch
Display type	VFD
Handle color	Stainless steel
Product type	Freestanding cooker
Product color	Black, Stainless steel
Built-in display	Yes
Control position	Front
Warming drawer position	Bottom
Grill	-
Oven size	Large
Number of ovens	1
Oven door opening	Drop down opening
Oven net capacity	160 L
Oven power source	Electric
Oven door material	Glass
Number of oven grids	2
Number of shelf positions	7
Oven interior dimensions (W x D x H)	609 x 482 x 558 mm
Hob type	Zone induction hob
Hob cover	No
Cooking zone 1 type	Small
Cooking zone 3 type	Medium
Cooking zone 1 power	1200 W
Cooking zone 3 power	3200 W
Cooking zone 4 power	2700 W
Cooking zone 1 diameter	152 mm
Cooking zone 1 position	Left rear
Cooking zone 2 position	Right rear
Cooking zone 3 diameter	228 mm
Cooking zone 3 position	Left front
Cooking zone 4 diameter	304 mm
Cooking zone 4 position	Right front
Number of cooking zones	5 zone(s)
Number of gas cooking zones	0 zone(s)
Package depth	762 mm
Package width	838 mm
Package height	1270 mm
Package weight	76636 g
Energy consumption (conventional)	- kWh

Weight and Dimensions

Depth	711 mm
Width	736 mm
Height	1193 mm
