LG LRE3193BD User Manual

-3-9-
COMPONENT ACCESS
1. Turn off the electrical supply going to the range.
2. Open the oven door and remove the racks from the oven.
3. Remove 2 screws from a bracket and pull the oven temperature sensor
forward in order to access a connector and disconnect the wirings.
• DISCONNECT power supply cord from the outlet
before servicing.
• Replace all panels and parts before operating.
•
RECONNECT all grounding devices.
- Failure to do so can result in severe personal injury, death or
electrical shock.
WARNING
• Be careful when you work on the electric range
handling the sheet metal part.
- Sharp edge may be present and you can cut yourself.
CAUTION
REMOVING THE OVEN TEMPERATURE SENSOR

LG LRE3193BD Specifications

General

Clock type	Electronic
Control type	Touch
Display type	VFD
Handle color	Stainless steel
Product type	Freestanding cooker
Product color	Black, Stainless steel
Built-in display	Yes
Control position	Front
Warming drawer position	Bottom
Grill	-
Oven size	Large
Number of ovens	1
Oven door opening	Drop down opening
Oven net capacity	160 L
Oven power source	Electric
Oven door material	Glass
Number of oven grids	2
Number of shelf positions	7
Oven interior dimensions (W x D x H)	609 x 482 x 558 mm
Hob type	Zone induction hob
Hob cover	No
Cooking zone 1 type	Small
Cooking zone 3 type	Medium
Cooking zone 1 power	1200 W
Cooking zone 3 power	3200 W
Cooking zone 4 power	2700 W
Cooking zone 1 diameter	152 mm
Cooking zone 1 position	Left rear
Cooking zone 2 position	Right rear
Cooking zone 3 diameter	228 mm
Cooking zone 3 position	Left front
Cooking zone 4 diameter	304 mm
Cooking zone 4 position	Right front
Number of cooking zones	5 zone(s)
Number of gas cooking zones	0 zone(s)
Package depth	762 mm
Package width	838 mm
Package height	1270 mm
Package weight	76636 g
Energy consumption (conventional)	- kWh

Weight and Dimensions

Depth	711 mm
Width	736 mm
Height	1193 mm
