COMPONENT ACCESS
This section instructs you on how to service each component inside the range. The components and their
locations are shown below.
COMPONENT LOCATIONS
Oven Sensor
Oven Light
Surface Elements
Main PCB
Hinge Hanger
Door Switch
Door Latch Assembly
Door Locking Motor
& Micro Switch
Convection Motor
Bake Heater
Broil Heater
