LG LRFDC2406 Series Technical Manual

LGEMM
Repair Instruction
s
embly, Fan
Warning: Check the components before replacing them.
NG OK
it is necessary to check the foam location around the edges on Grille, Fan.
Grille As
s
z
er
It is necessary to check the foam location around the edges on shroud.
NG
OK
Shroud Assembly, Free
z
It is necessary to check the foam location around the edges on shroud.
e
mbly, Fan
Shroud Assembly, Fan
Full Ass
e
Make sure all corners are properly sealed
Grill Assembly, Fan
30mm30mm
Evaporator Assembly
LG(61)-FO-DI-008.07
Check position of Sheath Heater. 30mm from the Left and Right side of liner

LG LRFDC2406 Series Specifications

General

Type	freestanding
Style	french door
Color	stainless steel
Number of Doors	3
Total Capacity	23.5 cubic feet
Refrigerator Capacity	15.4 cubic feet
Freezer Capacity	8.1 cubic feet
Humidity Controlled Crispers	yes
Minimum Refrigerator Temperature	55 degrees fahrenheit
Maximum Refrigerator Temperature	110 degrees fahrenheit
Defrost System	automatic
Number of Refrigerator Shelves	4
Temperature Control	electronic
Interior Light	led
Dispenser	ice and water
Ice Maker	yes
Water Filter	yes
Air Filter	yes
Door Alarm	yes
Smart Home	true, amazon alexa, google assistant
Wi-Fi	wi-fi
Annual Energy Consumption	700 kilowatt hours
Voltage	115 volts
Current	15 amperes

Weight and Dimensions

Depth	30 3/4 inches
Height	70 1/4 inches
Width	35 3/4 inches
Net Weight	300 pounds
