LG LRFDC2406 Series Technical Manual

1. Repair Instruction Rusting Issue SVC Guide
※ Reference : This bulletin does not change the service procedure.
This instruction is provided to clarify the service policy.
1) Expense Guide
- Top load washing machines within one (1) year after purchase (no charge).
2) Service Procedure
- If the cabinet top is rusting, the top plate, dispenser funnel and dispenser reservoir must all be replaced together,
using the regular service procedures available in the service manual.
Service Bulletin
Page 3
1) Remove the front panel and main PCB assembly
① Remove five (5) panel screws attaching the panel on
the back.
② Disassemble the rear panel.
③ Push the two (2) front deco hooks.
④ Disassemble the front deco.
⑤ Remove two (2) screws on the top cover.
⑥ Pull the front panel back.
Remove one (1) screw on the protect cover.
⑦ Disassemble the protective cover.
⑧ Disconnect the leads from the controller.
Product : Top loader washer
Bulletin # : DFZ201900071-02
Release Date : 2019.05.27

LG LRFDC2406 Series Specifications

General

Type	freestanding
Style	french door
Color	stainless steel
Number of Doors	3
Total Capacity	23.5 cubic feet
Refrigerator Capacity	15.4 cubic feet
Freezer Capacity	8.1 cubic feet
Humidity Controlled Crispers	yes
Minimum Refrigerator Temperature	55 degrees fahrenheit
Maximum Refrigerator Temperature	110 degrees fahrenheit
Defrost System	automatic
Number of Refrigerator Shelves	4
Temperature Control	electronic
Interior Light	led
Dispenser	ice and water
Ice Maker	yes
Water Filter	yes
Air Filter	yes
Door Alarm	yes
Smart Home	true, amazon alexa, google assistant
Wi-Fi	wi-fi
Annual Energy Consumption	700 kilowatt hours
Voltage	115 volts
Current	15 amperes

Weight and Dimensions

Depth	30 3/4 inches
Height	70 1/4 inches
Width	35 3/4 inches
Net Weight	300 pounds
