11-6 REFRIGERATION CYCLE
• Troubleshooting Chart
PARTIAL
LEAKAGE
Freezer
compartment and
Refrigeratordon't
cool normally.
Low flowing sound of
Refrigerant is heard
and frost forms in
inlet only.
A little higher than
ambient
temperature.
• Refrigerantlevelislowdue
to a leak.
• Normalcoolingispossibleby
restoring the normal amount
of refrigerant and repairing
the leak.
COMPLETE
LEAKAGE
Freezer
compartment and
Refrigeratordon't
cool normally.
Flowing sound of
refrigerant is not
heardandfrostisn't
formed.
Equal to ambient
temperature.
• Nodischargingof
Refrigerant.
• Normalcoolingispossibleby
restoring the normal amount
of refrigerant and repairing
the leak.
LEAKAGE
PARTIAL
CLOG
Freezer
compartment and
Refrigeratordon't
cool normally.
Flowing sound of
refrigerant is heard
and frost forms in
inlet only.
A little higher than
ambient
temperature.
• Normaldischargingofthe
refrigerant.
• Thecapillarytubeisfaulty.
WHOLE
CLOG
Freezer
compartment and
Refrigeratordon't
cool.
Flowing sound of
refrigerant is not
heardandfrostisn't
formed.
Equal to ambient
temperature.
• Normaldischargingofthe
Refrigerant.
MOISTURE CLOG Cooling operation
stops periodically.
Flowing sound of
refrigerant is not
heard and frost melts.
Lower than ambient
temperature.
• Coolingoperationrestarts
when heating the inlet of the
capillary tube.
CLOGGED BY DUST
COMP-
RESSION
Freezer and
Refrigeratordon't
cool.
Low flowing sound of
refrigerant is heard
and frost forms in
inlet only.
A little higher than
ambient
temperature.
• Lowpressureathighsideof
compressor due to low
refrigerant level.
NO COMP-
RESSION
No compressing
operation.
Flowing sound of
refrigerant is not
heard and there is
no frost.
Equal to ambient
temperature.
• Nopressureinthehigh
pressure part of the
compressor.
DEFECTIVE
COMPRESSION
CAUSE REMARKS
STATE OF THE
EVAPORATOR
TEMPERATURE
OF THE
COMPRESSOR
STATE OF
THE UNIT
11-6-1 Cleaning
There is no need for routine condenser cleaning in normal Home operating environments. If the environment is
particularly greasy or dusty, or there is significant pet traffic in the home, the condenser should be cleaned
every 2 to 3 months to ensure maximum efficiency.
If you need to clean the condenser:
｡｡
Remove the mechanical cover.
Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front
surface area of the condenser.
｡｡
Replace the mechanical cover.
-109-
Copyright © 2019 LG Electronics Inc.
All rights
reserved. Only training and service purposes.
