Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Table 2: Single Zone High Ef¿ciency Standard Wall Mount System Electrical Data.
Electrical
Nominal
Tons
Unit Model
No.
Hertz Voltage
Voltage
Range
(Min. to Max.)
MCA MOP
Compressor
Quantity
Compressor Motor
RLA Outdoor Fan Motor
Indoor
Fan
Motor
Cooling Heating
kW FLA FLA
3/4 LS090HSV5
60 208 - 230 187 - 253
10.0 15.0 1 7.0 7.0 0.043 0.4 0.4
1 LS120HSV5 10.0 15.0 1 7.0 7.0 0.043 0.4 0.4
1-1/2 LS180HSV5 13.0 20.0 1 9.6 9.6 0.124 0.25 0.4
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows:
(Largest motor FLA x 2.25) + (Sum of other motor FLA) rounded
down to the nearest standard fuse size.
RLA = Rated Load Amps.
FLA = Full Load Amps.
