LG LSC27950SW Service Manual

1-5. Dispenser operation circuit
(1) GR-L277SV(S)VA, SSWA (LSC27950SW, LSC27950SB, LSC27950ST, LSC27960ST)
1) Check load driving status
2) Lever Switch sensing circuit
EXPLANATION FOR MICOM CIRCUIT
- 30 -
Measuring part
Lever S/W
IC1(Micom) (No. 16)
On
OFF 5V
0 V
(60 Hz)
5 V
Measuring part IC7-15 IC7-14 IC7-13 IC7-12 IC7-11
Status
ON Within 1 V
OFF 12 V
Type of Load
GEARED
MOTOR
SOLENOID
CUBE
PILOT
VALVE
WATER VALVE
WATER
SOLENOID
DISPENSER
