COMPONENT ACCESS
3-2
1. Turn off the electrical supply going to the range.
2. Pull the range away from the wall so that you can
access the rear panel.
3. To remove the back cover, remove 8 screws from op
cover
4.
Remove the remaining 12 screws
REMOVING THE BACK COVER
REMOVING THE BACK COVER
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
CAUTION
•
Be careful when you work on the gas
range handling the sheet metal part.
- Sharp edge may be present and you can cut
yourself.
