LG LSG4513ST Service Manual

• LP (Propane) Gas Orifice Specifications
• Natural Gas Orifice Specifications
5-1
CONVERSION TO LP GAS
Denotes orifice
code
Top burner and
Bake burner orifices (W=W)
Broil burner
orifices
F
W
Denotes orifice
code
Top burner and
Bake burner orifices
Broil burner
orifices
A
C
BURNER OUTPUT RATINGS; BTU/HR
BTU RATE ORIFICE CODE
LF
LR
RR
RF
CTR
BROIL
BAKE
12,000
9,100
5,000
18,500
10,000
15,000
19,000
C
V
AA
U
T
A
H
Natural Gas, 5”W.C.P
BURNER
MODEL
CONVERTING THE SEALED BURNER MODEL
GAS RANGE FOR USE ON LP (PROPANE) GAS.
This range leaves the factory set for use with
natural gas. When converting to LP gas, keep these
instructions in case you need to convert back to
natural gas. And save the orifices removed from the
appliance for future use.
TOOLS REQUIRED:
• Adjustable wrench
• 13/32” or 10mm open-end wrench
5/16” or 8mm open-end wrench
16/32” or 16mm open-end wrench
• Phillips head screwdriver
• Flat bladed screwdriver(blade width approximately
3/32” across)
• Nut drivers : 13/32” or 10mm
5/16” or 8mm
WARNING
This conversion must be done by a qualified
technician or gas supplier in accordance
with the manufacturer’s instructions and all
codes and requirements of the authority
having jurisdiction. Failure to follow
instructions could result in serious injury or
property damage. The qualified agency
doing this work assumes responsibility for
the conversion.
CONVERSION KITS
LP(PROPANE) GAS
CONVERSION INSTRUCTIONS
BURNER OUTPUT RATINGS; BTU/HR
BTU RATE ORIFICE CODE
LF
LR
RR
RF
CTR
BROIL
BAKE
10,000
9,100
5,000
12,500
10,000
12,500
17,000
Q
M
W
G
Q
F
Y
UPSG3014 / LSSG3016 /
LSG4513 / LSG5513
UPSG3014 / LSSG3016 /
LSG4513 / LSG5513
LP(Propane) Gas. 10”W.C.P
M
Q
Q
G
W
[UPSG3014ST / LSSG3016ST/ LSG4513ST /
LSG5513ST / LSG5513BD]
LR
LF
RR
RF
CTR
※ CONVERSION POINT ※
1. Regulator
2. Bake burners
3. Broil Burner
4. Surface burners
①
②
③
④
BURNER
MODEL
