LG LSIL6334FE - Minimum and Maximum Pan Size; Cookware Compatibility Indicator

34 OPERATION
If the problem is not corrected, the affected
cooking element will automatically deactivate after
one minute.
Minimum and Maximum Pan Size
There are four cooking elements on the induction cooktop. Each element requires a appropriate pan size
to be used effectively. The bottom size of the pan must be between the maximum and minimum diameter
A for proper cooking to occur.
The pan must make full contact with the glass surface without the bottom of the pan touching the metal
cooktop trim.
If the correct induction cookware—centered on any of the active cooking elements—is too small, the pan
does not heat.
Cookware Compatibility Indicator
The cookware compatibility indicator shows how
efficiently the cookware will heat on the induction
cooktop elements.
1 Turn off all cooktop elements in use.
2 Put enough water in the cookware to cover
the bottom. Place the cookware on the center
of the desired cooktop element.
• Select an element that is appropriate for the
size of the cookware.
3 Set the power level on the selected element to
10.
4 Press Control Lock a and START b at the
same time for at least 3 seconds. The
indicator is shown on the display for 5
seconds.
Cooking Area
Heater
Diameter of Pan Bottom A
Type Size (inch) Min. Max.
a
Induction 8 7.5 inch (190 mm) 9.2 inch (224 mm)
b
Induction 11 9.5 inch (241 mm) 11.8 inch (300 mm)
c
Induction 6 5.5 inch (140 mm) 7.0 inch (178 mm)
d
Induction 6 5.5 inch (140 mm) 7.0 inch (178 mm)
