13INSTALLATION
ENGLISH
Choosing the Proper Location
Dimensions and Clearances
Dimensions
- Dimensions LSIL6336*
AWidth 29 7/8" (758.8 mm)
BHeight 36 1/2" (927.9 mm)
C Depth (Includes Door Handle) 29 9/32" (743.9 mm)
D Height (Excludes Vent Trim) 36" (913.0 mm)
E
Depth (Includes only the product body that is loaded into the cabinet.
Excludes door, drawer, and handles)
24 3/4" (629.4 mm)
F Depth (Excludes Door Handle) 26 7/8" (683 mm)
G Depth when drawer is fully opened 36 1/16" (916.2 mm)
H Depth when door is fully opened 48 5/8" (1235.9 mm)
