152
APPENDIX
APPENDIX
15. Balance (Command: k t)
► To adjust balance.
You can also adjust balance in the AUDIO menu.
Transmission
Data Min : 00 to Max : 64
*
Refer to ‘Real data mapping 1’. See page 153.
[k][t][ ][Set ID][ ][Data][Cr]
Ack
[t][ ][Set ID][ ][OK/NG][Data][x]
16. Colour Temperature (Command: x u)
► To adjust colour temperature. You can also adjust Colour
Temperature in the PICTURE menu.
Transmission
Data Min : 00 to Max : 64
*
Refer to ‘Real data mapping 1’. See page 153.
[x][u][ ][Set ID][ ][Data][Cr]
Ack
[u][ ][Set ID][ ][OK/NG][Data][x]
18. Auto Configure(Command: j u)
► To adjust picture position and minimize image shaking
automatically. It works only in RGB (PC) mode.
Transmission
Data 01: To set
[j][u][ ][Set ID][ ][Data][Cr]
Ack
Ack
[u][ ][Set ID][ ][OK/NG][Data][x]
[q][ ][Set ID][ ][OK/NG][Data][x]
17. Energy Saving (Command: j q)
► To reduce the power consumption of the TV. You
can also adjust Energy Saving in OPTION menu.
Transmission
[j][q][ ][Set ID][ ][Data][Cr]
Power Saving
Function
Level
Description
7 6 5 4 3 2 1 0
0 0 0 0 Low Power 0 0 0 0 Off
0 0 0 0 Low Power 0 0 0 1 Minimum
0 0 0 0 Low Power 0 0 1 0 Medium
0 0 0 0 Low Power 0 0 1 1 Maximum
0 0 0 0 Low Power 0 1 0 1 Screen Off
19.Tune Command (Command: m a)
► Select channel to following physical number.
Transmission
Data00 : High channel data
Data01 : Low channel data
ex. No. 47 -> 00 2F (2FH)
No. 394 -> 01 8A (18AH),
DTV No. 0 -> Don’t care
Data02 : 0x00 : Analogue Main
0x10 : DTV Main
0x20 : Radio
Channel data range
Analogue - Min: 00 to Max: 63 (0 to 99)
Digital - Min: 00 to Max: 3E7 (0 to 999)
(Except For Sweden, Finland, Norway, Denmark,
Ireland)
Digital - Min: 00 to Max: 270F (0 to 9999)
(Only Sweden, Finland, Norway, Denmark, Ireland)
[m][a][ ][Set ID][ ][Data0][ ][Data1][ ][Data2][Cr]
Ack
[a][ ][Set ID][ ][OK/NG][Data][x]
Data Min: 00 to Max: 7DH
