APPENDIX
23 . Input select ( Command: x b)
(Main Picture Input)
► To select input source for main picture.
Transmission
Data Structure
[x][b][ ][Set ID][ ][Data][Cr]
22. Back Light (Command: m g)
► To Control the back light.
Transmission
[m][g][ ][Set ID][ ][Data][Cr]
Ack
[g][ ][Set ID][ ][OK/NG][Data][x]
Ack
[b][ ][Set ID][ ][OK/NG][Data][x]
Data : data Min: 00 to Max: 64
21. Key(Command: m c)
► To send IR remote key code.
Transmission
Data Key code - Refer to page 148.
[m][c][ ][Set ID][ ][Data][Cr]
Ack
[c][ ][Set ID][ ][OK/NG][Data][x]
20. Programme Add/Skip(Command: m b)
► To set skip status for the current Programme.
Transmission
Data 00 : Skip 01 : Add
[m][b][ ][Set ID][ ][Data][Cr]
Ack
[b][ ][Set ID][ ][OK/NG][Data][x]
*
Real data mapping 1
00 : Step 0 Tint
Step 0 : R50
A : Step 10 (Set ID 10)
Step 49 : R1
F : Step 15 (Set ID 15) Step 50 : 0
10 : Step 16 (Set ID 16) Step 51 : G1
64 : Step 100 Step 100 : G50
6E : Step 110 Balance
Step 0 : L50
73 : Step 115
74 : Step 116 Step 49 : L1
Step 50 : 0
CF : Step 199 Step 51 : R1
FE : Step 254 Step 100 : R50
FF : Step 255
Colour Temperature
Step 0 : W50
Step 49 : W1
Step 50 : 0
Step 51 : C1
Step 100 : C50
Data 00: DTV 40: Component
10: Analogue 60: RGB
20: AV 90: HDMI
