LG M2380A User Manual

16
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
HD RECEIVER SETUP
When connecting with a component cable
■ To avoid damaging any equipment, never plug in any power cords until you have finished connecting
all equipment.
■ The image shown may be somewhat different from your set.
Connect the video outputs (Y, PB, PR) of the digital
set-top box to the COMPONENT IN VIDEO jacks on
the set.
Connect the audio output of the digital set-top box
to the COMPONENT IN AUDIO jacks on the set.
Turn on the digital set-top box. (Refer to the owner’s
manual for the digital set-top box.)
Select COMPONENT input source using the INPUT
button on the remote control.
1
2
3
4
Signal Component
480i / 576i O
480p / 576p O
720p O
1080i / 1080p O
A
U
DI
O
IN
(
RGB
)
H
/
P
H
DMI I
N
R
GB IN (PC)
ANTENNA
/
C
ABLE I
N
ANTENNA /
CABLE IN
VIDEO
Y P
B P R
L R
AUDIO
COMPONENT IN
VIDE
O
(MONO) L -
A
U
DI
O
- R
AV
IN
A
U
DI
O
IN
(
RGB
)
H
/
P
HDMI IN
R
GB IN
(
PC
)
ANTENNA
/
C
ABLE I
N
VIDE
O
Y
P
B
P
R
L
R
AUDIO
C
O
MP
O
NENT I
N
VIDE
O
(MONO) L -
AUDI
O
- R
AV
IN
1
2
Support resolution

LG M2380A Specifications

General

3D	No
Aspect ratio	16:9
Display diagonal	23 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	50000000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI-D ports quantity	0
RMS rated power	5 W
Number of speakers	2
Height adjustment	-
Panel mounting interface	75 x 75 mm
Power consumption (standby)	1 W
Power consumption (typical)	33 W
Product color	Black

Weight and Dimensions

Depth (with stand)	194 mm
Height (with stand)	416 mm
Weight (with stand)	4300 g
Depth (without stand)	58 mm
Width (without stand)	547 mm
Height (without stand)	350 mm
Weight (without stand)	4100 g
