LG M3204CCBA

10
Name and Function of the Parts
Rear View
* The product image in the user's guide could be different from the actual image.
Power Connector
Connect the power cord
RS-232C Serial Ports
RGB, HDMI/DVI Ports
HDMI Supports High Definition input and HDCP (High-bandwidth Digital Content
Protection). Some devices require HDCP in order to display HD signals.
PC Sound Jack
Connect the audio cable to the *LINE OUT jack of the PC sound card.
1
2
4
3
1 2
43 65 87
