19
• Select Component.
Connect the video/audio cable as shown in the below figure and then, connect
the power cord (See page 12).
• Connect the input terminal with a proper color match.
• 1080p is Only on M4716C model.
BNC Cable
(not included)
Product
HDTV Receiver
Select an input signal.
Press the INPUT button on the remote control to select the input signal.
Or, press the INPUT button on the back of the product.
Audio Cable
(not included)
Connecting to External Devices
Note
- Some devices may require HDCP in order to display HD signals.
- Component doesn't support HDCP.
INPUT → → OK
1
2
INPUT →◄ ► → AUTO/SET
Input List
AV Component RGB HDMI/DVI SuperSign
Component Input (480i/480p/576i/576p/720p/1080i/1080p)
To Next Page
