Controlling the Multiple Product
RS-232C
A15
21. Tile H Position(Command : d e)
► To set the Horizontal position.
Transmission
Data Min : 00H to Max : 14H
00H : Step -10(Left)
14H : Step 10(Right)
Acknowledgement
22. Tile V Position(Command : d f)
► To set the Vertical position.
Transmission
Data Min : 00H to Max : 14H
00H : Step -10(Down)
14H : Step 10(Up)
Acknowledgement
Transmission / Receiving Protocol
[d][e][ ][Set ID][ ][Data][x]
[e][ ][Set ID][ ][OK/NG][Data][x]
[d][f][ ][Set ID][ ][Data][x]
[f][ ][Set ID][ ][OK/NG][Data][x]
