10
Check that the computer, monitor and the peripherals are turned off. Then, connect the
signal input cable.
Connecting with a D-Sub Signal Input Cable.
Connecting with an HDMI-DVI Signal Input Cable (not included)
* When HDMI PC is used, a compatibility problem may occur.
MAC
Macintosh Adapter (not included)
Use the standard Macintosh adapter since an incompatible adapter
that uses a different signaling system is available on the market.
Connecting to External Devices
Connect the power cord.
PC
PC/MAC
PC
PC
Rear back of the set.
Rear back of the set.
Rear back of the set.
Connect the Audio cable.
(not included)
(not included)
* Use shielded signal interface cables (D-sub 15 pin cable, HDMI-DVI cable) with ferrite cores
to maintain standard compliance with your set.
Connecting to Your PC
1
2
3
B.
B.
A.
A.
Rear back of the set.
To Next Page
