Controlling Multiple Set
RS-232C
A6
03. Aspect Ratio(Command : c) (Main picture format)
► To adjust the screen format.
You can also adjust the screen format using the ARC
(Aspect Ratio Control) button on remote control or in the
Screen menu.
Transmission
Data 1 : Normal Screen (4 : 3)
2 : Wide Scran (16 : 9)
4 : Zoom (AV)
6 : Original (AV)
7 : 14 : 9 (AV)
9 : Just Scan (HD DTV) * When the RGB, HDMI / DVI PC mode(1:1)
10 to 1F : Cinema Zoom 1 to 16
B : Full Wide
Acknowledgement
04. Screen Mute(Command : d)
► To select screen mute on / off.
Transmission
Data 0 : Screen mute off (Picture on)
1 : Screen mute on (Picture off)
Acknowledgement
Transmission / Receiving Protocol
[k][c][ ][Set ID][ ][Data][Cr]
[k][d][ ][Set ID][ ][Data][Cr]
[c][ ][Set ID][ ][OK][Data][x]
[d][ ][Set ID][ ][OK][Data][x]
