Controlling Multiple Set
RS-232C
A13
18. Auto Configure(Command: j u)
► To adjust picture position and minimize image shaking
automatically. it works only in RGB(PC) mode.
Transmission
Data 1 : To set
Acknowledgement
Transmission / Receiving Protocol
19. Key(Command : m c)
► To send IR remote key code.
Transmission
Data Key code : Refer to page A 32.
Acknowledgement
[j][u][ ][Set ID][ ][Data][Cr]
[u][ ][Set ID][ ][OK][Data][x]
[m][c][ ][Set ID][ ][Data][Cr]
[c][ ][Set ID][ ][OK][Data][x]
