4-17
Copyright © 2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
[Figure B-6-a]
• The Final Assembly
1) Put the Loading FFC down through the square hole of the Base Main.
2) Push the Tray Loading with a hand softly until heard the hook.
1
2
