4
Attaching the speakers to the unit
Setting up
Remote control Operation
Point the Remote Control at the display window and press the buttons.
Remote control Battery Installation
1 Detach the battery cover on the rear of the remote control
2 Insert the R03 (size AAA) battery with 3 and # aligned correctly.
Be careful of the following
• Be careful to make sure children not to put their hands or any objects into the
*speaker duct.
* Speaker duct : A hole for plentiful bass sound on speaker cabinet
(enclosure).
Grey
Red
Green
Orange
Blue
White
Rear
Front
Center
Sub Woofer
Rear
Front
Behind you and to your right.
In front of you, to the right of the screen.
Above screen, directly in front of you.
This can be placed in any front position.
Behind you and to your left.
In front of you, to the left of the screen.
POSITION
SPEAKER
COLOUR
Connect the black end of each wire to the terminals marked - (minus) and the
other end to the terminals marked + (plus).
To connect the cable to the each speakers, press each plastic finger pad to
open the connection terminals on the back of each speaker. Insert the wire and
release the finger pad.
MDS714 (5.1 channel)
Red
White
Orange
Front
Front
Sub Woofer
In front of you, to the right of the screen.
In front of you, to the left of the screen.
This can be placed in any front position.
POSITION
SPEAKER
COLOUR
MDT364 (2.1 channel)
Red
White
Front
Front
In front of you, to the right of the screen.
In front of you, to the left of the screen.
POSITION
SPEAKER
COLOUR
MDD264 (2 channel)
To Next Page
