2-2. Install Dust filter & keep temperature 0°C ~ 40°C (Mandatory)
• Embedded Mount Condition
• Application model : NC1000, NA1000, NA1100, MP500, PC100
• Minimum distance between media player and structure : 100mm distance to X,Y,Z axis direction
•Should install dust filter in ventilation area
• When the unit is operating, you must keep temperature inside being 0°C ~ 40°C
100mm
100mm
100mm
100mm
100mm
Ventilation
Ventilation
Ventilation
Hot air
Cool air
▪ Dust filter
Enclosure
Media player
