LG Monitor User Manual

1-2. Consider using a cooling & heater solution (Mandatory)
 To maintain the temperature inside the enclosure, you may consider using a cooling
and heater solution such as an air conditioner, heat exchanger, or combined cooler
and heater depending on the external environment. (Please see below examples)
 You can also employ an air flow circulation system and air curtain* between the front
panel and the enclosure.
Example 2 : Enclosure (Heat exchanger) Example 1 : Enclosure (Just fans)
Example 4 : Direct Air Cooling Solution Example 3 : Enclosure (Air conditioner)
Air Curtain
Air Curtain
Air Curtain
Air Curtain
Heater
Membrane Filter
FAN
Humidity Sensor
Protection
glass
 Recommend to design the exterior of the enclosure to meet with the IP65 standard.
 Use a dust filter to prevent dust .(At air inlet and outlet )
Filter should be used for filtering out bugs, dust and water.
For preventing from rust of lead frame in circuit board,
operates the Heater if relative humidity is high.
*Air curtain :
Air flow circulation system between
the front panel and the enclosure.
