VESA 200X200 : ± 10 mm (Leveling)
VESA 400X400 : ± 10 mm (Leveling)
6
Horizontal Level Adjustment
If the set is not correctly horizontal aligned after the installation, adjust it using the ❶ screw.
(The product tilt is changed according to bolt’s rotation direction.)
