LG MULTI F A2UW16GFA0 - Page 215

Heat pump 50Hz/R410A _ 5
2. Distributor type MULTI F DX (1 phase)
Part 2 Product data_Outdoor units
[Heating capacity]
16 10,560 3.1 17,600 5.2 21,120 6.2 820 1,120 1,826
18 11,880 3.5 19,800 5.8 23,760 7.0 820 1,260 2,054
19 12,540 3.7 20,900 6.1 25,080 7.4 825 1,330 2,168
21 13,860 4.1 23,100 6.8 27,720 8.1 911 1,470 2,396
23 15,180 4.4 25,300 7.4 30,360 8.9 998 1,610 2,624
24 15,840 4.6 26,400 7.7 31,680 9.3 1,042 1,680 2,738
25 16,500 4.8 27,500 8.1 33,000 9.7 1,085 1,750 2,853
26 17,160 5.0 28,600 8.4 34,320 10.1 1,128 1,820 2,967
27 17,820 5.2 29,700 8.7 35,640 10.4 1,172 1,890 3,081
28 18,480 5.4 30,800 9.0 36,960 10.8 1,215 1,960 3,195
29 19,140 5.6 31,900 9.3 38,280 11.2 1,259 2,030 3,309
30 19,800 5.8 33,000 9.7 39,600 11.6 1,302 2,100 3,423
31 20,460 6.0 34,100 10.0 40,920 12.0 1,345 2,170 3,537
32 21,120 6.2 35,200 10.3 42,240 12.4 1,389 2,240 3,651
33 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765
34 22,440 6.6 37,400 11.0 44,880 13.2 1,476 2,380 3,879
35 23,100 6.8 38,500 11.3 46,200 13.5 1,519 2,450 3,994
36 23,760 7.0 39,600 11.6 47,520 13.9 1,562 2,520 4,108
37 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222
38 25,080 7.4 41,800 12.3 50,160 14.7 1,649 2,660 4,336
39 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
40 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
41 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
42 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
43 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
44 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
45 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
46 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
47 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
48 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
49 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
50 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
51 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
52 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
Total indoor unit
capacity
(kBtu/h)
Min
Heating capacity
Rated Max
Btu/h kW Btu/h kW Btu/h kW
Min Rated Max
Input (W)
Note :
1. Cooling Capacity is based on : indoor temp.27°C DB, 19°C WB
; outdoor temp. 35°C DB, 24°C WB
2. Heating Capacity is based on : indoor temp.20°C DB, 15°C WB
; outdoor temp. 7°C DB, 6°C WB
3. The rated capacities above show the rise in the total indoor unit capacity when operating frequency is constant.
Values for changes in capacity are fixed after accounting for variations in operating frequency and should be used as reference values.
4. Total capacity index of indoor unit should be within 16~52 kBtu/h(40%~130%)
5. At least two indoor units should be connected.
