2. Distributor type MULTI F DX (1 phase)
6 _ Heat pump 50Hz/R410A
Part 2 Product data_Outdoor units
Models : A8UW48GFA0 [FM48AH U32]
[Cooling capacity]
19 11,400 3.3 18,535 5.4 20,900 6.1 840 1,222 1,665
20 12,000 3.5 19,510 5.7 22,000 6.4 880 1,282 1,746
21 12,600 3.7 20,486 6.0 23,100 6.8 920 1,341 1,827
22 13,200 3.9 21,461 6.3 24,200 7.1 960 1,401 1,908
23 13,800 4.0 22,437 6.6 25,300 7.4 1,000 1,460 1,989
24 14,400 4.2 23,412 6.9 25,705 7.5 1,085 1,520 2,071
25 15,000 4.4 24,388 7.1 26,776 7.8 1,128 1,579 2,152
26 15,600 4.6 25,363 7.4 27,847 8.2 1,170 1,639 2,233
27 16,200 4.7 26,339 7.7 28,918 8.5 1,213 1,698 2,314
28 16,800 4.9 27,314 8.0 29,989 8.8 1,256 1,758 2,395
29 17,400 5.1 28,290 8.3 31,060 9.1 1,298 1,817 2,476
30 18,000 5.3 29,265 8.6 32,131 9.4 1,355 1,897 2,584
31 18,600 5.5 30,241 8.9 33,202 9.7 1,412 1,976 2,693
32 19,200 5.6 31,216 9.1 34,273 10.0 1,468 2,056 2,801
33 19,800 5.8 32,192 9.4 35,344 10.4 1,525 2,135 2,909
34 20,400 6.0 33,167 9.7 36,415 10.7 1,582 2,215 3,018
35 21,000 6.2 34,143 10.0 37,486 11.0 1,639 2,294 3,126
36 21,600 6.3 35,118 10.3 38,557 11.3 1,696 2,374 3,235
37 22,200 6.5 36,094 10.6 39,628 11.6 1,752 2,453 3,343
38 22,800 6.7 37,069 10.9 40,699 11.9 1,809 2,533 3,451
39 23,400 6.9 38,045 11.2 41,770 12.2 1,866 2,613 3,560
40 24,000 7.0 39,020 11.4 42,841 12.6 1,923 2,692 3,668
41 24,600 7.2 39,996 11.7 43,912 12.9 1,980 2,772 3,776
42 25,200 7.4 40,971 12.0 44,983 13.2 2,037 2,851 3,885
43 25,800 7.6 41,947 12.3 46,054 13.5 2,093 2,931 3,993
44 26,400 7.7 42,922 12.6 47,125 13.8 2,122 2,971 4,047
45 27,000 7.9 43,898 12.9 48,196 14.1 2,150 3,010 4,102
46 27,600 8.1 44,873 13.2 49,268 14.4 2,179 3,050 4,156
47 28,200 8.3 45,849 13.4 50,339 14.8 2,207 3,090 4,210
48 28,800 8.4 46,824 13.7 51,410 15.1 2,236 3,130 4,265
49 29,400 8.6 47,800 14.0 52,481 15.4 2,264 3,170 4,319
50 30,000 8.8 48,164 14.1 52,881 15.5 2,299 3,219 4,373
51 30,600 9.0 48,529 14.2 53,281 15.6 2,335 3,269 4,428
52 31,200 9.1 48,893 14.3 53,680 15.7 2,370 3,318 4,482
53 31,800 9.3 49,257 14.4 54,080 15.9 2,405 3,367 4,537
54 32,400 9.5 49,621 14.5 54,480 16.0 2,440 3,416 4,591
55 33,000 9.7 49,986 14.6 54,880 16.1 2,476 3,466 4,645
56 33,600 9.8 50,350 14.8 55,280 16.2 2,511 3,515 4,700
57 34,200 10.0 50,714 14.9 55,680 16.3 2,546 3,564 4,754
58 34,800 10.2 51,079 15.0 56,080 16.4 2,581 3,614 4,808
59 35,400 10.4 51,443 15.1 56,480 16.6 2,616 3,663 4,863
60 36,000 10.6 51,807 15.2 56,880 16.7 2,652 3,712 4,917
61 36,600 10.7 52,171 15.3 57,280 16.8 2,687 3,761 4,971
62 37,200 10.9 52,536 15.4 57,680 16.9 2,722 3,811 5,026
63 37,800 11.1 52,900 15.5 58,080 17.0 2,757 3,860 5,080
Total indoor unit
capacity
(kBtu/h)
Min
Cooling capacity
Rated Max
Btu/h kW Btu/h kW Btu/h kW
Min Rated Max
Input (W)
Note :
1. Cooling Capacity is based on : indoor temp.27°C DB, 19°C WB
; outdoor temp. 35°C DB, 24°C WB
2. Heating Capacity is based on : indoor temp.20°C DB, 15°C WB
; outdoor temp. 7°C DB, 6°C WB
3. The rated capacities above show the rise in the total indoor unit capacity when operating frequency is constant.
Values for changes in capacity are fixed after accounting for variations in operating frequency and should be used as reference values.
4. Total capacity index of indoor unit should be within 19~63 kBtu/h(40%~130%)
5. At least two indoor units should be connected.
