LG MULTI F A2UW16GFA0 - Page 26

Heat Pump 50Hz/R410A _ 11
1. Multiple piping type MULTI F
Part 2 Product data_Outdoor units
Note :
1. Cooling Capacity is based on : indoor temp.27°CDB, 19°CWB
; outdoor temp. 35°CDB, 24°CWB
2. Heating Capacity is based on : indoor temp.20°CDB, 15°CWB
; outdoor temp. 7°CDB, 6°CWB
3. Maximum total capacity index of connected indoor units is 30 kBtu/h.
4. At least two indoor units should be connected to outdoor unit.
5. Total capacity of indoor units connected should be minimum 40% of outdoor unit rated capacity.
5 - - 5 1.6 - - 4,800 1.4 5,500 1.6 6,325 1.9 180 425 733
7 - - 7 2.5 - - 4,800 1.4 8,400 2.5 9,660 2.8 252 595 1,027
1 Unit 9 - - 9 3.2 - - 6,480 1.9 10,800 3.2 12,420 3.6 324 765 1,320
12 - - 12 4.2 - - 8,640 2.5 14,400 4.2 16,560 4.9 432 1,020 1,760
18 - - 18 6.3 - - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 5 - 10 1.8 1.8 - 7,200 2.1 12,000 3.5 13,800 4.0 360 850 1,467
5 7 - 12 1.8 2.5 - 8,640 2.5 14,400 4.2 16,560 4.9 432 1,020 1,760
5 9 - 14 1.8 3.2 - 10,080 3.0 16,800 4.9 19,320 5.7 504 1,190 2,053
5 12 - 17 1.8 4.2 - 12,240 3.6 20,400 6.0 23,460 6.9 612 1,445 2,493
5 18 - 23 1.8 6.3 - 16,560 4.9 27,600 8.1 31,740 9.3 648 1,955 3,373
7 7 - 14 2.5 2.5 - 10,080 3.0 16,800 4.9 19,320 5.7 504 1,190 2,053
2 Unit 7 9 - 16 2.5 3.2 - 11,520 3.4 19,200 5.6 22,080 6.5 576 1,360 2,347
9 9 - 18 3.2 3.2 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
7 12 - 19 2.3 4.0 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
9 12 - 21 3.2 4.2 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
12 12 - 24 3.2 3.2 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
7 18 - 25 1.8 4.6 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
9 18 - 27 2.1 4.2 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
12 18 - 30 2.5 3.8 - 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 5 5 15 1.8 1.8 1.8 10,800 3.2 18,000 5.3 20,700 6.1 540 1,275 2,200
5 5 7 17 1.8 1.8 2.5 12,240 3.6 20,400 6.0 23,460 6.9 612 1,445 2,493
5 5 9 19 1.7 1.7 3.0 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 5 12 22 1.4 1.4 3.5 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 7 7 19 1.7 2.3 2.3 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 7 9 21 1.5 2.1 2.7 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 7 12 24 1.3 1.8 3.2 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 9 9 23 1.4 2.5 2.5 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
3 Unit 5 9 12 26 1.2 2.2 2.9 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
5 12 12 29 1.1 2.6 2.6 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
7 7 7 21 2.1 2.1 2.1 12,960 3.8 21,600 6.3 24,840 7.3 769 1,530 2,640
7 7 9 23 1.9 1.9 2.5 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
7 9 9 25 1.8 2.3 2.3 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
7 7 12 26 1.7 1.7 2.9 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
9 9 9 27 2.1 2.1 2.1 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
7 9 12 28 1.6 2.0 2.7 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
9 9 12 30 1.9 1.9 2.5 12,960 3.8 21,600 6.3 24,840 7.3 648 1,530 2,640
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Heating
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Total Unit-A Unit-B Unit-C Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
Heating
