1. Multiple piping type MULTI F
12 _
Heat Pump
50Hz/R410A
Part 2 Product data_Outdoor units
Models : A3UW21GFA0 [MU3U21 UE2]
Cooling
Note :
1. Cooling Capacity is based on : indoor temp.27°CDB, 19°CWB
; outdoor temp. 35°CDB, 24°CWB
2. Heating Capacity is based on : indoor temp.20°CDB, 15°CWB
; outdoor temp. 7°CDB, 6°CWB
3. Maximum total capacity index of connected indoor units is 33 kBtu/h.
4. At least two indoor units should be connected to outdoor unit.
5. Total capacity of indoor units connected should be minimum 40% of outdoor unit rated capacity.
5 - - 5 1.5 - - 4,800 1.4 5,000 1.5 5,500 1.6 140 376 562
7 - - 7 2.1 - - 6,300 1.8 7,000 2.1 7,700 2.3 140 527 787
1 Unit 9 - - 9 2.6 - - 6,300 1.8 9,000 2.6 9,900 2.9 252 677 1,011
12 - - 12 3.5 - - 7,200 2.1 12,000 3.5 13,200 3.9 336 903 1,349
18 - - 18 5.3 - - 10,800 3.2 18,000 5.3 19,800 5.8 504 1,354 2,023
5 5 - 10 1.5 1.5 - 6,000 1.8 10,000 2.9 11,000 3.2 280 752 1,124
5 7 - 12 1.5 2.1 - 7,200 2.1 12,000 3.5 13,200 3.9 336 903 1,349
5 9 - 14 1.5 2.6 - 8,400 2.5 14,000 4.1 15,400 4.5 392 1,053 1,573
7 7 - 14 2.1 2.1 - 8,400 2.5 14,000 4.1 15,400 4.5 392 1,053 1,573
7 9 - 16 2.1 2.6 - 9,600 2.8 16,000 4.7 17,600 5.2 448 1,204 1,798
5 12 - 17 1.5 3.5 - 10,200 3.0 17,000 5.0 18,700 5.5 476 1,279 1,910
2 Unit 9 9 - 18 2.6 2.6 - 10,800 3.2 18,000 5.3 19,800 5.8 504 1,354 2,023
7 12 - 19 2.1 3.5 - 11,400 3.3 19,000 5.6 20,900 6.1 532 1,430 2,135
9 12 - 21 2.6 3.5 - 12,600 3.7 21,000 6.2 23,100 6.8 588 1,580 2,360
5 18 - 23 1.5 5.3 - 13,800 4.0 21,000 6.2 23,100 6.8 588 1,580 2,360
12 12 - 24 3.4 3.4 - 13,800 4.0 21,000 6.2 23,100 6.8 588 1,580 2,360
7 18 - 25 2.0 5.1 - 14,400 4.2 21,000 6.2 23,100 6.8 588 1,580 2,360
9 18 - 27 2.3 4.7 - 14,400 4.2 21,000 6.2 23,100 6.8 588 1,580 2,360
12 18 - 30 2.8 4.2 - 14,400 4.2 21,000 6.2 23,100 6.8 588 1,580 2,360
5 5 5 15 1.5 1.5 1.5 9,000 2.6 15,000 4.4 18,000 5.3 420 1,129 1,686
5 5 7 17 1.5 1.5 2.1 10,200 3.0 17,000 5.0 20,400 6.0 476 1,279 1,910
5 5 9 19 1.5 1.5 2.6 11,400 3.3 19,000 5.6 22,800 6.7 532 1,430 2,135
5 7 7 19 1.5 2.1 2.1 11,400 3.3 19,000 5.6 22,800 6.7 532 1,430 2,135
5 7 9 21 1.5 2.1 2.6 12,600 3.7 21,000 6.2 25,000 7.3 588 1,580 2,360
7 7 7 21 2.1 2.1 2.1 12,600 3.7 21,000 6.2 25,000 7.3 588 1,580 2,360
5 5 12 22 1.5 1.5 3.5 13,200 3.9 21,000 6.2 25,000 7.3 588 1,580 2,360
7 7 9 23 2.1 2.1 2.6 13,800 4.0 21,000 6.2 25,000 7.3 588 1,580 2,360
5 9 9 23 1.5 2.6 2.6 13,800 4.0 21,000 6.2 25,000 7.3 588 1,580 2,360
5 7 12 24 1.5 2.1 3.5 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
7 9 9 25 2.0 2.5 2.5 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
3 Unit 5 9 12 26 1.4 2.4 3.2 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
7 7 12 26 1.9 1.9 3.2 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
9 9 9 27 2.3 2.3 2.3 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
7 9 12 28 1.8 2.3 3.0 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
5 5 18 28 1.3 1.3 4.5 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
5 12 12 29 1.2 2.9 2.9 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
5 7 18 30 1.2 1.6 4.2 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
9 9 12 30 2.1 2.1 2.8 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
7 12 12 31 1.6 2.7 2.7 14,400 4.2 21,000 6.2 25,000 7.3 588 1,580 2,360
5 9 18 32 1.1 2.0 4.0 14,400 4.2 21,000 6.3 25,000 7.3 588 1,580 2,360
7 7 18 32 1.5 1.5 4.0 14,400 4.2 21,000 6.3 25,000 7.3 588 1,580 2,360
9 12 12 33 1.9 2.6 2.6 14,400 4.2 21,000 6.3 25,000 7.3 588 1,580 2,360
Combination
(kBtu/h)
Each capacity
(kW)
Total Capacity (kW)
Cooling
Min Rated Max
Input
(W)
Unit-A Unit-B Unit-C Total Unit-A Unit-B Unit-C Btu/h kW Btu/h kW Btu/h kW Min Rated Max
Operation
