OUTDOOR UNITS INFORMATION
9
ENGLISH
Power Supply : 3Ø, 380V, 60Hz or 3Ø, 380 - 415V, 50Hz
Model Name : A(B)RUV***LTS4
CAUTION
Notes : * We can guarantee the operation only within 130% Combination.
If you want to connect more than 130% combination, please contact us and dis-
cuss the requirement like below.
• If the operation of indoor unit is more than 130%, the airflow is operated as low in the all
indoor units.
• The number of ( ) means the number of Max. connectable indoor units, when the con-
nected capacity of indoor units is in the table above.
Combination Ratio(50~200%)
Outdoor Number Connection Ratio
Single outdoor units 200%
Double outdoor units 160%
Triple outdoor units 130%
!
OUTDOOR UNITS INFORMATION
Unit 1 Outdoor unit
HP
10 12 14
Model Name
Combination Unit
A(B)RUV100LTS4 A(B)RUV120LTS4 A(B)RUV140LTS4
Independent Unit A(B)RUV100LTS4 A(B)RUV120LTS4 A(B)RUV140LTS4
Pipe
Connctions
Liquid mm(inch) 9.52(3/8) 12.7(1/2) 12.7(1/2)
Gas mm(inch) 22.2(7/8) 28.58(1 1/8) 28.58(1 1/8)
Dimensions(WxHxD)
mm (920×1,680×760)×1 (920×1,680×760)×1 (920×1,680×760)×1
inch
(36-7/32×66-5/32×29-29/32)×1 (36-7/32×66-5/32×29-29/32)×1 (36-7/32×66-5/32×29-29/32)×1
Net Weight
kg 185 × 1 195 × 1 195 × 1
lbs 408 × 1 430 × 1 430 × 1
Refigerant
Refigerant name R410A R410A R410A
Precharged
Amount
kg555
lbs 11.0 11.0 11.0
Number of maxmum connectable indoor units 16(25) 20(30) 23(35)
Unit 1 Outdoor unit
HP
16 18 20
Model Name
Combination Unit
A(B)RUV160LTS4 A(B)RUV180LTS4 A(B)RUV200LTS4
Independent Unit A(B)RUV160LTS4 A(B)RUV180LTS4 A(B)RUV200LTS4
Pipe
Connctions
Liquid mm(inch) 12.7(1/2) 15.88(5/8) 15.88(5/8)
Gas mm(inch) 28.58(1 1/8) 28.58(1 1/8) 28.58(1 1/8)
Dimensions(WxHxD)
mm (1,240×1,680×760)×1 (1,240×1,680×760)×1 (1,240×1,680×760)×1
inch
(48-13/16×66-5/32×29-29/32)×1 (48-13/16×66-5/32×29-29/32)×1 (48-13/16×66-5/32×29-29/32)×1
Net Weight
kg 235 × 1 270 × 1 270 × 1
lbs 518 × 1 595 × 1 595 × 1
Refigerant
Refigerant name R410A R410A R410A
Precharged
Amount
kg 6 6.5 6.5
lbs 13.2 14.3 14.3
Number of maxmum connectable indoor units 26(40) 29(45) 32(50)
