LG Multi V CRUN Series Installation Manual

60 Outdoor Unit
System Check List
Prior to power on
(Remarks)
Outdoor unitIndoor unit
INSPECTION ITEM
Breaker capacity Visual inspection Specified capacity
Air filter Visual inspection
Refrigerant
piping system
Gas leak detector No leakage
Heat exchanger Visual inspection
No clogging or
damage
Heat exchanger Visual inspection
No clogging or
damage
No clogging or
damage
Installation
condition
Airtight Test with
Nitrogen gas
Evacuation
Under 2.94 Mpa for 24 hours or more
Under the pressure of 5 tor.
for 3 hours or more
YES NO
YES NO
Visual inspection Short-circuit, etc.
Installation
condition
Visual inspection Short-circuit, etc.
Refrigerant
piping system
Gas leak detector No leakage
YES NO
Good Bad
Terminal
connection
Screwdriver, etc. No loosening
Good
No. 1
Bad
Good
Room A G/B Room B G/B Room C G/B Room D G/B
Room E G/B Room F G/B Room G G/B Room H G/B
Room I G/B Room J G/B Room K G/B Room L G/B
Room M G/B Room N G/B Room O G/B Room P G/B
Bad
Fan motor
insulation
500V mega tester Over 1MΩ
Fan motor
insulation
500V mega tester Over 1MΩ
Aux. heater
insulation
500V mega tester Over 1MΩ
Compressor
insulation
500V mega tester Over 1MΩ
MΩ
MΩ No. 2 MΩ
A
INSPECTION
METHOD
Judge-
ment
STANDARD ACTUAL MEASUREMENT
Room A G/B Room B G/B Room C G/B Room D G/B
Room E G/B Room F G/B Room G G/B Room H G/B
Room I G/B Room J G/B Room K G/B Room L G/B
Room M G/B Room N G/B Room O G/B Room P G/B
Room A G/B Room B G/B Room C G/B Room D G/B
Room E G/B Room F G/B Room G G/B Room H G/B
Room I G/B Room J G/B Room K G/B Room L G/B
Room M G/B Room N G/B Room O G/B Room P G/B
Room A G/B Room B G/B Room C G/B Room D G/B
Room E G/B Room F G/B Room G G/B Room H G/B
Room I G/B Room J G/B Room K G/B Room L G/B
Room M G/B Room N G/B Room O G/B Room P G/B
Room A G/B Room B G/B Room C G/B Room D G/B
Room E G/B Room F G/B Room G G/B Room H G/B
Room I G/B Room J G/B Room K G/B Room L G/B
Room M G/B Room N G/B Room O G/B Room P G/B
Room A G/B Room B G/B Room C G/B Room D G/B
Room E G/B Room F G/B Room G G/B Room H G/B
Room I G/B Room J G/B Room K G/B Room L G/B
Room M G/B Room N G/B Room O G/B Room P G/B
