System Engineering
60
|
SYSTEM ENGINEERING
Due to our policy of continuous product innovation, some specifications may change without notification.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Figure 26: Side by Side—high rear and
front walls with building overhang
Note:
Installation clearances must
comply with local building
codes.
All gures not to scale.
Legend:
LR = Rear wall height
LF = Front wall height
H = Unit height
L
egend:
L
R = Rear wall hei
g
ht
L
F = Front wall hei
g
ht
H = Unit hei
g
h
t
Figure 29: Side by Side—high rear wall
and low front wall with no side walls
Figure 30: Double Row Units—low rear and
front walls with no side walls or overhang
Figure 32: Side by Side—high rear
wall and low front wall with building
overhang and no side walls
Figure 28: Side by Side—high front
wall with building overhang and no
side or rear walls
Figure 31: Side by Side—high front and
rear walls with no side walls
CLEARANCE REQUIREMENTS
Outdoor Unit Minimum Clearance
Airflow
Figure 27: Single Row Units—high rear
wall and low front wall with no side walls or
overhang
Max 20”
Min 40”
Min 4”
Min 40”
Min 40”
Min 12”
Airow
1
000 (39-1/4)
or m
ore
100(3-15/16)
or more
1000 (39-1/4)
or more
500(19-5/8) or less
Airflow
Airflow
Airflow
Airflow
1000 (39-1/4)
or more
100(3-15/16)
or more
1000 (39-1/4)
or more
500(19-5/8) or less
Airflow
Airflow
H L
300(11-7/8)
or more
500(19-5/8)
or less
1000 (39-1/4)
or more
H
L
1500(59)
or more
100(3-15/16)
or more
When installed in predominately cold climates:
• Install a eld-provided snow hood to keep out snow and rain.
Ensure the outdoor unit is installed to avoid direct contact with snow. If the unit is installed in a snowy area, attach a eld-
provided snow hood over the coil inlet and/or outlet. If snow accumulated and freezes on the fan inlet and/or outlet, the
system may malfunction.
Install the outdoor unit at least 19-3/4 inches higher than the average annual snowfall.
The height of the mounting base must be more than 2 times the average annual snowfall.
The width of the mounting base must not exceed the width of the unit. Snow may accumulate if the width of the frame is
wider than that of the unit.
Make sure the fan inlet and the fan discharge of the outdoor unit are facing away from the seasonal wind.
Figure 25: Side by Side—high rear
and side walls with building overhang
