Setting of comfort cooling operation
Master unit PCB DIP switch on : No.5
Select the mode using ‘▶’, ‘◀’ Button :
“Idu” Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
“Id10” Push the ‘●’ button
EEV pulse appearing
(seg1, seg2:Idu No./seg3, seg4:Mode)
Select the Function using ‘▶’, ‘◀’ Button :
Idu No. setting and Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
Mode setting and Push the ‘●’ button
*Mode can be set 0~3 (”0” is no setting)
Setting of comfort cooling operation
Mode setting Effect
0 No setting
1 Cooling capacity low,Power consumption low
2 Cooling capacity mid,Power consumption mid
3 Cooling capacity high,Power consumption high
Comfort Cooling operation (Id 10)
It is function to reduce the ODU energy consumption by the continuou
s operation without thermo off.
Mode setting method
