LG Multi V System

Installation
Installation Manual 23
ENGLISH
3. 2 Remote Control
■ Wired remote controller 2 + Indoor unit 1
1. It is possible to connect two wired remote controllers with one indoor unit.
2. Every types of indoor unit is possible to connect two remote controller.
3. It is possible to use wireless remote controller at the same time.
4. It is possible to connect with Dry Contact and Central controller at the same time.
5. In case of any error occurs at indoor unit, display on the wired remote controller.
6. There isn’t limits of indoor unit function.
GND
Signal
12 V
LGAP Network System
Display Error Message
Master
Master
Slave
