LG NS9550F - Wiring Diagram

3-41 3-42
VFD
FRONT
10P, 2 mm
10P, 2 mm
Portable
MIC
MIC Vol
MIC & Portable
10P, 2 mm
10P, 1.25 mm
15P, 2.5 mm6P, 3.96 mm
SMPS
15P, 2.5 mm6P, 3.96 mm
40P, 1.25 mm
MD
1
MAIN
FAN
40P, 1.25 mm
0P, 1 mm
WIRING DIAGRAM
