(1) Put the set on the flat pad.
(2) Remove Rear Small Cover
- Pull up bottom of Rear Small Cover to remove.
(3) Remove Stand Screw and Stand
FAB30016103 (M4*12mm), 4EA
- Remove Screw 4EA first, next remove Stand
(4) Remove Back Cover Screw
FAB31843216 (M3*5.5mm, Gray) 9EA
-> Common use 55”/65”
FAB31843216 (M3*5.5mm, Gray) 1EA
-> Add only 55”
DISASSEMBLY
